Technical Specification

Working Voltage

DC24V

Working Current

Monitoring current: ≤ 120μA

Maximum operating current: ≤ 7mA

Wiring

Two-wire, polarity-free

Addressing Method

Electrical encoder

Address Range

1–254

Alarm Volume

75 dB–115 dB @ 3 m (A)

Modulation Cycle

4 s–5 s

Flash Rate

1.5Hz–2.0Hz

Communication Distance

1500 m (4921.26 ft)

Operating Temperature

–10°C to +55°C (+14°F to +131°F)

Storage Temperature

–20°C to +65°C (–4°F to +149°F)

Operating Humidity

≤ 95% RH (no condensation)

Color

Shell: Red

Lampshade: Clear white

Dimensions

125 mm × 80 mm × 40 mm (4.92″ × 3.15″ × 1.57″)

Weight (with base)

118 g (0.26 lb)

Compliance Standard

EN54-3, EN54-23
